SOAR-A

IP Ultra Latency, A/V & Data Together, Secure & Simple Operation
The Revolutionary IP Flexible & Customizable Solution

  • Ultra Low Latency
    realized by optimized software architecture and broadcast quality unique OS

  • Multiple Video, Audio and Data
    can be securely transferred packed together bi-directionally with simple set up

  • SD, HD, 4K & NDI to SMPTE ST2110 :
    Flexible and customizable configuration and channel expandability

  • Streaming via WebRTC to Any browser & Anywhere
    No gateway, no specific players needed. Targeted contents can be seen anytime, anywhere, anybody


Solution Line Up

SOAR-A EDGE IP Transport Appliance

IP Transport Appliance

IP transport appliance solutions, which realize ultra low latency under highly secured platform. It could be perfect for not only just IP ENC/DEC, but also especially, REMI application, by flexible, expandable and upgradable architecture.



Multiple video, audio transfer

SDI, NDI®, variety of streams such as WebRTC, WebM, HLS/DASH, CMAF, MP4

Ultra low latency preview with WebRTC

Adaptive bitrate streaming

Powerful RIST tunnel

Point-to-multipoint including multilink and multicast

Seamless switching without glitching between stream copies based on 2022-7

Load balancing (Bonding) for faster connection

Secure connection with PSK (Pre-Shared Key) supplemented with SRP (Secure Remote Password) and DTLS (Datagram Transport Layer Security)

Packet recovery (upper loss threshold=40-55%)

Simple and flexible VPN to connect multiple sites

  • SOAR-A EDGE Mini
    Assignable 2ch/Compact/FAN less

  • SOAR-A EDGE Server
    4ch to up to 16ch/1RU server/Redundant power supply

SOAR-A IPTV IPTV Distribution Service

IPTV Distribution Service

IPTV is IP distribution service, which provide ultra low latency and scalable streaming on cluster for anyone to monitor anywhere, any browser.


  • Ultra low latency WebRTC streaming
  • Highly scalable WebWTC streaming on clusters
  • Live video monitoring and surveillance(Monitor your ONVIF IP Cameras with ultra-low latency on your web browser. No need to install any custom software.)
  • 7/24 camera recording
  • SOAR-A IPTV IPTV Distribution Service

    Revolutionary Ease of Use Production Graphic Engine

    Learn More

  • SOAR-A IPTV IPTV Distribution Service

    Revolutionary Ease of Use Multi Channel Media Server

    Learn More


System Example: SOAR-A EDGE
Simple Remote Production


Connecting a remote camera location to your broadcast studio using a SOAR-A allows you transmit SDI/NDI/IP video channels configured as either Encode or Decode. Each RIST Tunnel can carry up to ten streams of multiplexed media and send to up to ten peers.

Adding VPN function allows additional network ports for control and intercom signals. This enables a simple network architecture that passes all traffic through a single set up UDP ports.


System Example: SOAR-A EDGE
Advanced Remote Broadcast Production


In this example we are using SOAR-A to provide more bi-directional media channels and a cloud router to send the signals between multiple studios and remote production offices.


System Example: SOAR-A IPTV
Simple IPTV Production


Connecting a remote camera location to your broadcast studio only requires a single device located at the meeting head end. The meeting feed may be received by SOAR-A set top boxes at each remote office, which allow viewing on dedicated displays. Or viewers may view the meeting via web GUI on standard computers, tablets and phones.


Application by Segment

  • Broadcast

    - Contribution/distribution
    - Live sports remote production
    - Local interview to station
    - IPTV to view contents anywhere

  • Corporate

    - Event remote production
    - Live high-quality distribution
    - Hybrid IP base event
    - Nation and worldwide streaming distribution

  • House of worship

    - Event remote production
    - Remote access and control
    - Live distribution among several campus
    - Nation and worldwide streaming distribution

NDI® is a registered trademark of Vizrt Group.
